The SRX3 is a triple-slot housing, which allows to plug all arcutronix’s rack mount cards. The SRX3 can be used in a 19’’-shelf or as desk-top application. A flexible front adaptor allows to use the SRX3 with lots of different product groups and families. Together with a multi voltage power supply unit, which allows AC or DC feeding, the SRX3 is the most flexible standalone chassis with 1RU in high.
Two variants of SRX3 are available which differ in the management capability. While the SRX3 offers serial access to all plugged Line Cards for basic configuration and supervision, the SRX3plus houses internally a complete management agent (SCX2). Thus SRX3plus offers all capabilities of management access, including web-based, SNMP and IP-telnet. This making the SRX3plus to powerful system in 1RU size, completing arcutronix’ Multi Service Platfom (MSP).
The SRX3 offers a VT100 (RS232) serial interface, for configuration and local supervision of the installed Line Cards. The SRX3plus has in addition an RJ45 connector TCP/IP access. A 10/100BaseT interface allows local or remote management access and integration into higher network systems. Both variants are equipped with alarm-output, which completes the unique feature-set of the SRX3.
The SRX3plus can be supplied with AC or DC power. For SRX3 only AC power supply is available.
